Kenwood KT-8300

AM/FM Stereo Tuner (1976-79)

Description

The Kenwood KT-8300 is designed to the highest standards and is an ideal match for the KA-8300 amplifier.

Specifications

Type: Mono/Stereo Tuner

Tuning Bands: FM, MW

Tuning Scale: Analogue

FM Tuning Range: 88 to 108 MHz

Sensitivity: 1.6uV (FM), 18uV (MW)

Signal to Noise Ratio: 75dB (FM), 50dB (MW)

Distortion: 0.4% (FM)

Selectivity: 110dB (FM), 35dB (MW)

Frequency response: 20Hz to 15kHz (FM)

Output: 750mV (FM), 75mV (MW)

Dimensions: 430 x 149 x 376mm

Weight: 8.5kg

Year: 1976
