Revox A77 Reel to Reel in Speaker Case * Manual * Reels * Accessories
Reels on deck are NOT included
Reels in case cover ARE included
Revox A77
3 Motor 2 Speed Reel to Reel Tape Recorder (1971-74)
Description
The well known reliability of the Revox A77 is a result of a professional design concept, a concept which successfully combines the advantages of a solidly built tape transport mechanism with those of an advanced electronic circuit design.
A 3 motor transport mechanism with electronically regulated capstan motor and solenoid operated servo brakes possesses few parts which are subject to mechanical wear.
The use of a die-cast motor chassis and head support ensures that a high degree of mechanical precision and long term stability are maintained, even under excessively heavy use.
The mechanical and electrical properties thus complement each other in a most successful way.
Models include the A77 professional, A77 SLS (super low speed) for up to 12 hours of recording, and the A77 Autostart (Vox) for security applications.
Specifications
Motor: 2 x reel, 1 x capstan
Reel size: up to 10.5 inch reel
Equalization: NAB, IEC
Tape speeds: 3 3⁄4 7 1⁄2 ips
Wow and flutter: 0.08% (7 1⁄2 ips)
Frequency response: 30Hz to 20kHz (7 1⁄2 ips)
Signal to Noise Ratio: 62dB
Total harmonic distortion: 0.6%
Crosstalk: 45dB
Input: 35mV (line), 0.15mV (mic)
Output: 1.2V (line)
Output power: 8 watts
Semiconductors: 54 x transistors, 32 x diodes,
Dimensions: 415 x 359 x 180mm
Weight: 33lbs
Original: $600.00
-70%$600.00
$180.00
