Sansui 5000X Stereo Receiver * 60W RMS * 1972
Sansui 5000X
AM/FM Stereo Tuner Amplifier (1971-72)
Specifications
Tuning range: FM, MW
Power output: 60 watts per channel into 8Ω (stereo)
Frequency response: 10Hz to 50kHz
Total harmonic distortion: 0.5%
Damping factor: 50
Input sensitivity: 3mV (mic), 2.5mV (MM), 150mV (DIN), 150mV (line)
Signal to noise ratio: 70dB (MM), 75dB (line)
Channel separation: 40dB (MM), 45dB (line)
Output: 200mV (line), 35mV (DIN)
Speaker load impedance: 4Ω to 16Ω
Semiconductors: 3 x FET, 4 x IC, 52 x transistors, 31 x diodes, 3 x zener diodes
Dimensions: 462 x 162 x 338mm
Weight: 15.1kg
Year: 1971
Original: $600.00
-70%$600.00
$180.00
Description
Sansui 5000X
AM/FM Stereo Tuner Amplifier (1971-72)
Specifications
Tuning range: FM, MW
Power output: 60 watts per channel into 8Ω (stereo)
Frequency response: 10Hz to 50kHz
Total harmonic distortion: 0.5%
Damping factor: 50
Input sensitivity: 3mV (mic), 2.5mV (MM), 150mV (DIN), 150mV (line)
Signal to noise ratio: 70dB (MM), 75dB (line)
Channel separation: 40dB (MM), 45dB (line)
Output: 200mV (line), 35mV (DIN)
Speaker load impedance: 4Ω to 16Ω
Semiconductors: 3 x FET, 4 x IC, 52 x transistors, 31 x diodes, 3 x zener diodes
Dimensions: 462 x 162 x 338mm
Weight: 15.1kg
Year: 1971
