Sansui 7070 Stereo Receiver * 60W RMS * 1976
Sansui 7070
AM/FM Stereo Receiver (1976-78)
Description
The Sansui 7070 is an advanced electronic design in the medium-power/medium-price range.
It has 65 watts, both channels driven into 8 ohms at 1000Hz, giving you adequate power to drive two sets of full-size speaker systems.
Features include a highly sensitive MOS FET FM front-end and a Dolby FM adaptor terminal.
Specifications
Tuning range: FM, MW
Power output: 60 watts per channel into 8Ω (stereo)
Frequency response: 20Hz to 30kHz
Total harmonic distortion: 0.3%
Damping factor: 45
Input sensitivity: 2.5mV (mic), 2.5mV (MM), 150mV (line)
Signal to noise ratio: 70dB (MM), 80dB (line)
Channel separation: 50dB (MM), 50dB (line)
Output: 150mV (line), 30mV (DIN)
Speaker load impedance: 4Ω to 8Ω
Dimensions: 502 x 156 x 371mm
Weight: 16.6kg
Year: 1976
Original: $850.00
-70%$850.00
$255.00
