Teac 3340 Reel to Reel 4 Channel Simul-Sync Stereo Tape Deck
METAL REEL TAPES ARE NOT INCLUDED
TEAC A-3340
4 Channel Simul-Sync Stereo Tape Deck (1974-76)
Description
The TEAC A-3340 is a semi-professional tape deck capable of 4-channel, stereophonic and monophonic recording and playback, with Simul-Sync function, and offering operating speeds of 15 ips and 7.5 ips
Specifications
Track system: 4-track, 4-channel, stereo/monaural/multi channel system
Heads: 1 x erase, 1 x record, 1 x playback
Motor: 2 x reel, 1 x capstan
Reel size: up to 10.5 inch reel
Tape speeds: 7 1⁄2 15 ips
Wow and flutter: 0.04% (15 ips)
Frequency response: 25Hz to 24kHz (15 ips)
Signal to Noise Ratio: 55dB
Total harmonic distortion: 1%
Input: 100mV (line), 0.25mV (mic)
Output: 0.775V (line)
Dimensions: 522 x 440 x 170mm
Weight: 22.5kg
Accessories: TZ-612 reel adaptor, connection cord
Original: $800.00
-70%$800.00
$240.00
