Teac A2300SX Reel to Reel Recorder 7 inch
TEAC A-2300SX
Stereo Reel to Reel Tape Recorder (1976)
Description
The A-2300SX features a cue lever for fast search, cueing and editing.
Independent left and right channel tape/source selectors offer improved monitoring capabilities and provide sound on sound (with some repatching).
Specifications
Track system: 4-track, 2-channel, stereo/monaural system
Heads: 1 x erase, 1 x record, 1 x playback
Motor: 2 x reel, 1 x capstan
Reel size: 5 or 7 inch reel
Equalization: NAB
Tape speeds: 3Ā 3ā4Ā Ā 7Ā 1ā2Ā ips
Wow and flutter: 0.2%Ā (7Ā 1ā2Ā ips)
Signal to Noise Ratio: 48dB
Total harmonic distortion: 1.5%
Crosstalk: 35dB
Input: 97mV (line), 0.25mV (mic)
Output: 0.3V (line)
Dimensions: 440 x 392 x 210mm
Weight: 18kg
Description
TEAC A-2300SX
Stereo Reel to Reel Tape Recorder (1976)
Description
The A-2300SX features a cue lever for fast search, cueing and editing.
Independent left and right channel tape/source selectors offer improved monitoring capabilities and provide sound on sound (with some repatching).
Specifications
Track system: 4-track, 2-channel, stereo/monaural system
Heads: 1 x erase, 1 x record, 1 x playback
Motor: 2 x reel, 1 x capstan
Reel size: 5 or 7 inch reel
Equalization: NAB
Tape speeds: 3Ā 3ā4Ā Ā 7Ā 1ā2Ā ips
Wow and flutter: 0.2%Ā (7Ā 1ā2Ā ips)
Signal to Noise Ratio: 48dB
Total harmonic distortion: 1.5%
Crosstalk: 35dB
Input: 97mV (line), 0.25mV (mic)
Output: 0.3V (line)
Dimensions: 440 x 392 x 210mm
Weight: 18kg
